EP/NN/CC dipped fabric > EP DIPPED FABRIC >
EE/NN/CC dipped fabric
- Dipped EP Fabric
- EP fabric Unit EP80 EP100 EP125 EP150 EP160 EP200
- Warp Weft Warp Weft Warp Weft Warp Weft Warp Weft Warp Weft
- Material - Warp: Polyester Yarn Weft: Nylon-6.6 Yarn
- Breaking Strength N/cm ≥1050 ≥450 ≥1350 ≥500 ≥1600 ≥650 ≥1900 ≥700 ≥2100 ≥700 ≥2400 ≥800
- Elongation @break % ≥14 ≤45 ≥14 ≤45 ≥14 ≤45 ≥14 ≤45 ≥14 ≤45 ≥14 ≤45
- Hot Air Shrinkage (150℃ x 30min) % ≤5.0 ≤0.5 ≤5.0 ≤0.5 ≤5.0 ≤0.5 ≤5.0 ≤0.5 ≤5.0 ≤0.5 ≤5.0 ≤0.5
- Peel Adhesion N/mm ≥8.0 ≥8.0 ≥8.0 ≥8.0 ≥8.0 ≥8.0
- Dry Weight Per Square Meter g/m2 320±15 360±20 435±20 520±20 560±20 630±30
- Thickness mm 0.45±0.05 0.55±0.05 0.60±0.05 0.70±0.05 0.75±0.05 0.85±0.10
- Width cm 50--190
- INQUIRY
Dipped NN Fabric
NN fabric | Unit | NN80 | NN100 | NN125 | NN150 | NN160 | NN200 | ||||||
Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | ||
Material | - | Warp: Nylon-6 Yarn Weft: Nylon-6 Yarn | |||||||||||
Breaking Strength | N/cm | ≥1050 | ≥400 | ≥1250 | ≥500 | ≥1500 | ≥550 | ≥1750 | ≥650 | ≥2000 | ≥700 | ≥2300 | ≥750 |
Elongation @break | % | ≤25 | ≤55 | ≤25 | ≤55 | ≤25 | ≤50 | ≤25 | ≤50 | ≤25 | ≤50 | ≤26 | ≤50 |
Hot Air Shrinkage (150℃ x 30min) | % | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 |
Peel Adhesion | N/mm | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ||||||
Dry Weight Per Square Meter | g/m2 | 285±15 | 310±20 | 345±15 | 400±20 | 440±20 | 500±20 | ||||||
Thickness | mm | 0.45±0.05 | 0.50±0.05 | 0.52±0.05 | 0.58±0.05 | 0.65±0.05 | 0.75±0.10 | ||||||
Width | cm | 50--190 | |||||||||||
NN fabric | Unit | NN250 | NN300 | NN350 | NN400 | NN450 | NN500 | ||||||
Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | Warp | Weft | ||
Material | - | Warp: Nylon-6 Yarn Weft: Nylon-6 Yarn | |||||||||||
Breaking Strength | N/cm | ≥2800 | ≥800 | ≥3500 | ≥800 | ≥4000 | ≥900 | ≥4500 | ≥850 | ≥5000 | ≥850 | ≥5550 | ≥850 |
Elongation @break | % | ≤26 | ≤50 | ≤27 | ≤50 | ≤29 | ≤50 | ≤29 | ≤50 | ≤29 | ≤50 | ≤29 | ≤50 |
Hot Air Shrinkage (150℃ x 30min) | % | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 | ≤5.5 | ≤0.5 |
Peel Adhesion | N/mm | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ≥8.0 | ||||||
Dry Weight Per Square Meter | g/m2 | 590±20 | 710±30 | 820±40 | 930±40 | 1100±40 | 1200±50 | ||||||
Thickness | mm | 0.90±0.10 | 1.10±0.15 | 1.22±0.15 | 1.25±0.15 | 1.50±0.15 | 1.60±0.15 | ||||||
Width | cm | 50--190 | |||||||||||
